269.6DU Gable Duplex House Plan | 6 Bed | 4 Bath | Dual Living Design | 2901 Sq Ft
Create a spacious and practical dual-living investment property with the 269.6DU Gable Duplex House Plan. Designed with two mirror-image residences, this modern duplex offers generous family living, open-plan layouts, private alfresco entertaining areas, and attractive gable roof styling.
Perfect for investors, multi-generational families, dual occupancy developments, or rental income opportunities, each residence provides a comfortable 3-bedroom layout with its own garage and outdoor living space.
Complete Construction Plans & Working Drawings Package – Ready for Building Approval
Free Custom Modifications to Suit Your Land and Lifestyle
Please Note: After purchase, we will contact you to obtain your building site address and confirm any modifications or custom changes required before we commence and complete your plans.
🏡 Plan Features
✔ 6 Bedrooms Total (3 Per Residence)
✔ 4 Bathrooms (2 Per Residence)
✔ 4 Living Areas Across Both Homes
✔ 2 Meals Areas
✔ 2 Family-Sized Kitchens
✔ 2 Single Garages
✔ Private Alfresco Entertaining Areas
✔ Gable Roof Design
✔ Open Plan Living & Dining Layout
✔ Ideal Investment or Multi-Generational Home
📐 Overall Building Size
Width: 21.8 m (71' 6")
Length: 12.75 m (41' 10")
Total Building Area:
269.6 m² | 2,901 Sq Ft
Unit 1 Areas
Metric
| Area | Size |
|---|---|
| Living Area | 102.3 m² |
| Garage | 18.7 m² |
| Porch | 5.6 m² |
| Alfresco | 8.2 m² |
| Total Area | 134.8 m² |
Feet & Inches
| Area | Size |
|---|---|
| Living Area | 1,101 Sq Ft |
| Garage | 201 Sq Ft |
| Porch | 60 Sq Ft |
| Alfresco | 88 Sq Ft |
| Total Area | 1,450 Sq Ft |
Unit 2 Areas
Metric
| Area | Size |
|---|---|
| Living Area | 102.3 m² |
| Garage | 18.7 m² |
| Porch | 5.6 m² |
| Alfresco | 8.2 m² |
| Total Area | 134.8 m² |
Feet & Inches
| Area | Size |
|---|---|
| Living Area | 1,101 Sq Ft |
| Garage | 201 Sq Ft |
| Porch | 60 Sq Ft |
| Alfresco | 88 Sq Ft |
| Total Area | 1,450 Sq Ft |
Perfect For
- Property Investors
- Duplex Developments
- Rental Income Properties
- Multi-Generational Families
- Dual Occupancy Housing
- Corner or Wide Residential Lots
The 269.6DU Gable Duplex House Plan combines practical family living with strong investment potential, delivering two comfortable 3-bedroom homes under one attractive gable roof design.
What's Included in Your Construction Plans / Working Drawings Package
Your professionally prepared Construction Plans (Working Drawings) package includes:
✓ Dimensioned Floor Plans
✓ Exterior Elevations (All Sides)
✓ Building Sections and Construction Details
✓ Roof Plan
✓ Door and Window Schedules
✓ Electrical Layout Plan
✓ Lighting and Power Point Locations
✓ Internal Room Dimensions and Areas
✓ Building Notes and Specifications
✓ Structural Bracing and Tie-Down Details
✓ Footing and Foundation Design (site-specific soil test required)
✓ Licensed Structural Engineering Documentation
✓ 3D Colour Perspectives / Facade Images
✓ Site-Specific Modifications to Suit Your Land and Requirements
✓ PDF Digital Delivery
Please Note:
• Final footing and slab designs require a site-specific soil test.
• We will contact you after purchase to obtain your building site address and discuss any required modifications.
• Additional council requirements may vary depending on your local authority and building location.
Structural Engineering Included
All plans in this package include structural engineering prepared by a licensed professional engineer.
Please note that final footing and slab designs are specific to your site conditions and require a soil test for the property where you intend to build. Once you provide the building site address, we can assist with obtaining soil test pricing and arranging this service on your behalf.
