227 Haven RH Garage Apartment Plan | 3 Bedroom + Office | 227.9 m² | 2454 Sq Ft
Modern Garage Apartment with Spacious Living & Large Balcony
The 227 Haven RH Garage Apartment Plan is a spacious and versatile two-level design that combines modern living with practical functionality. Featuring 3 bedrooms, a dedicated office, 4 bathrooms, and a large balcony, this design is ideal for owner-builders, guest accommodation, multigenerational living, Airbnb rentals, or a premium garage apartment residence.
The upper level provides generous open-plan living with a modern kitchen, dining, and living area flowing onto a large outdoor balcony. The lower level offers additional accommodation and flexible living options, making this a highly adaptable design for a wide range of applications.
Complete Construction Plans & Working Drawings Package – Ready for Building Approval
Free Custom Modifications to Suit Your Land and Lifestyle
Please Note: After purchase, we will contact you to obtain your building site address and confirm any modifications or custom changes required before we commence and complete your plans.
Plan Features
- 3 Bedrooms
- Dedicated Office
- 4 Bathrooms
- Open Plan Kitchen
- Large Living Area
- Large Entertaining Balcony
- Robes to Bedrooms
- Two Level Design
- Ideal for Airbnb or Rental Accommodation
- Suitable for Owner Builders
- Available for Modification
Metric Area Sizes
| Area | Size |
|---|---|
| Lower Floor | 105.3 m² |
| Upper Floor | 97.4 m² |
| Balcony | 25.2 m² |
| Total Area | 227.9 m² |
Imperial Area Sizes
| Area | Size |
| Lower Floor | 1134 Sq Ft |
| Upper Floor | 1048 Sq Ft |
| Balcony | 271 Sq Ft |
| Total Area | 2454 Sq Ft |
Metric Room Sizes
| Room | Size |
| Bedroom 1 | 3.6 m × 3.3 m |
| Bedroom 2 | 3.6 m × 3.3 m |
| Living Room | 6.7 m × 4.2 m |
Room Sizes Feet & Inches
| Room | Size |
| Bedroom 1 | 11' 10" × 11' 0" |
| Bedroom 2 | 11' 10" × 11' 0" |
| Bedroom 3 | 11' 2" × 11' 5" |
| Living Area | 22' 0" × 11' 10" |
Plan Details
Design: 227 Haven RH
Style: Garage Apartment Plan
Bedrooms: 3
Bathrooms: 4
Office: Yes
Total Area: 227.9 m² | 2454 Sq Ft
What's Included in Your Construction Plans / Working Drawings Package
Your professionally prepared Construction Plans (Working Drawings) package includes:
✓ Dimensioned Floor Plans
✓ Exterior Elevations (All Sides)
✓ Building Sections and Construction Details
✓ Roof Plan
✓ Door and Window Schedules
✓ Electrical Layout Plan
✓ Lighting and Power Point Locations
✓ Internal Room Dimensions and Areas
✓ Building Notes and Specifications
✓ Structural Bracing and Tie-Down Details
✓ Footing and Foundation Design (site-specific soil test required)
✓ Licensed Structural Engineering Documentation
✓ 3D Colour Perspectives / Facade Images
✓ Site-Specific Modifications to Suit Your Land and Requirements
✓ PDF Digital Delivery
Please Note:
• Final footing and slab designs require a site-specific soil test.
• We will contact you after purchase to obtain your building site address and discuss any required modifications.
• Additional council requirements may vary depending on your local authority and building location.
Structural Engineering Included
All plans in this package include structural engineering prepared by a licensed professional engineer.
Please note that final footing and slab designs are specific to your site conditions and require a soil test for the property where you intend to build. Once you provide the building site address, we can assist with obtaining soil test pricing and arranging this service on your behalf.
