The 169.48 LH Narrow is a smart and stylish traditional home design created specifically for slim and narrow blocks. Featuring 3 bedrooms, a separate media room, open-plan living to the rear, and a large covered alfresco area, this design combines practicality with modern family living.

Designed to maximise space and natural light, this home offers a functional layout with a spacious kitchen and pantry, open family living area, and a private master suite. The rear alfresco connects seamlessly to the living area, making it ideal for entertaining and relaxed indoor-outdoor living.

Perfect for growing families, first home buyers, developers, or investment projects on narrow blocks.

Key Features

✔ 3 Bedroom Narrow Lot Home Design
✔ Separate Home Media Room
✔ 2 Modern Bathrooms
✔ Spacious Kitchen with Pantry
✔ Open Plan Living & Dining Area
✔ Covered Rear Alfresco Patio
✔ Double Garage
✔ Traditional Family-Friendly Layout
✔ Ideal for Slim & Narrow Blocks

Home Sizes (Metric)

Area Sizes

• Living Area: 110.6 m²
• Porch Area: 2.26 m²
• Garage Area: 36.44 m²
• Alfresco Area: 20.2 m²
• Total Area: 169.48 m²

Room Sizes (Metric)

• Bed 1: 3.6 m × 3.0 m
• Bed 2: 3.0 m × 3.0 m
• Bed 3: 3.0 m × 3.0 m
• Media Room: 3.5 m × 3.6 m
• Lounge: 4.9 m × 4.2 m

Room Sizes (Feet & Inches)

• Bed 1: 11'10” × 9'10”
• Bed 2: 9'9” × 9'9”
• Bed 3: 9'9” × 9'9”
• Media Room: 11'5” × 11'10”
• Lounge: 16'0” × 11'1”

House Areas (Feet & Inches)

• Living Area: 1190 Sq Ft
• Garage Area: 391 Sq Ft
• Porch Area: 24 Sq Ft
• Alfresco Area: 217 Sq Ft
• Total Area: 1822 Sq Ft

Perfect For

• Narrow & Slim Blocks
• Family Homes
• Investment Properties
• Estate Developments
• First Home Buyers
• Modern Australian Living
• Owner Builders & Builders

What's Included in Your Construction Plans / Working Drawings Package

Your professionally prepared Construction Plans (Working Drawings) package includes:

✓ Dimensioned Floor Plans
✓ Exterior Elevations (All Sides)
✓ Building Sections and Construction Details
✓ Roof Plan
✓ Door and Window Schedules
✓ Electrical Layout Plan
✓ Lighting and Power Point Locations
✓ Internal Room Dimensions and Areas
✓ Building Notes and Specifications
✓ Structural Bracing and Tie-Down Details
✓ Footing and Foundation Design (site-specific soil test required)
✓ Licensed Structural Engineering Documentation
✓ 3D Colour Perspectives / Facade Images
✓ Site-Specific Modifications to Suit Your Land and Requirements
✓ PDF Digital Delivery

 Please Note:

• Final footing and slab designs require a site-specific soil test.
• We will contact you after purchase to obtain your building site address and discuss any required modifications.
• Additional council requirements may vary depending on your local authority and building location.

Structural Engineering Included

All plans in this package include structural engineering prepared by a licensed professional engineer.

Please note that final footing and slab designs are specific to your site conditions and require a soil test for the property where you intend to build. Once you provide the building site address, we can assist with obtaining soil test pricing and arranging this service on your behalf.
